Solenso x SOLARC
Electrical protection
Circuit breakers, type B RCBOs, surge protectors, transfer switches, voltage relays and contactors: the Solenso x SOLARC selection protects the consumer unit and the solar installation connected to it. Solenso is its official distributor in Europe, with after-sales service in France.
- references
- 8references
- device families
- 6device families
- breaking capacity
- 10 kAbreaking capacity
- backup switchover
- < 50 msbackup switchover
MCBMiniature circuit breaker
SOLARC SCB3-63
- Ratings
- 1 to 63 A
- Breaking Capacity
- 6 kA or 10 kA
- Curves
- B, C and D
- Standard
- IEC/EN 60898-1
RCBORCBO
SOLARC SCB3LE-63B type B
- Residual Current Type
- Type B
- Sensitivity
- 30 to 300 mA
- Ratings
- 6 to 63 A
- Poles
- 1P+N or 3P+N
SPDSurge protector
SOLARC SCS-40 type 2
- Maximum Current
- Imax 40 kA
- Protection Level
- Up ≤ 1.8 kV
- Nominal Current
- In 20 kA
- Voltage Uc
- 275 V AC
ATSAutomatic transfer switch
SOLARC SCTS2-63
- Transfer Time
- < 50 ms
- Ratings
- 6 to 63 A
- Poles
- 2P or 4P
- Class
- PC, IEC 60947-6-1
ATSAutomatic transfer switch
SOLARC SCTS3-100
- Ratings
- 16 to 100 A
- Transfer Time
- < 50 ms
- Poles
- 2P, 3P or 4P
- Class
- PC, AC-33iB
OUVPOver and under voltage protection
SOLARC SCS6-VA2 single-phase
- Maximum Current
- 40, 63, 80 or 100 A
- Overvoltage Setting
- 130 to 300 V
- Undervoltage Setting
- 80 to 210 V
- Accuracy
- < 1%
OUVPOver and under voltage protection
SOLARC SCS6-N6VA2 three-phase
- Supply
- Three-phase 380/400 V
- Faults Monitored
- Voltage, current, phases
- Display
- 6 LED displays
- Accuracy
- 2% on voltage
CTModular contactor
SOLARC SCH8-40
- AC-7a Current
- 40 A
- AC-7b Current
- 18 A
- Coil
- 230 V AC, 50/60 Hz
- Contacts
- 2 NO, 1 NO + 1 NC or 2 NC
Official SOLARC distributorElectrical and PV protection
Protecting a solar installation, from panel to consumer unit
A photovoltaic installation adds an energy source to the consumer unit, and with it new risks. Electrical protection starts with a circuit breaker sized on the inverter output current, backed by residual current protection. Some inverters and EV chargers can produce DC leakage currents that blind a standard RCD: the SCB3LE-63B type B RCBO detects them. Connected to the roof panels as well as to the grid, the equipment is also exposed to lightning on both sides, hence the SCS-40 type 2 surge protector in the consumer unit.
Next come the devices that keep the installation available. The SCS6-N6VA2 relay disconnects the supply when the voltage of a phase drifts, before appliances suffer, and restores it on its own. The SCTS2-63 transfer switch moves to a generator or an off-grid inverter in under 50 ms when the grid goes down. Finally, the SCH8-40 contactor lets a water heater run on surplus production without its load passing through the control module. The whole range fits a 35 mm DIN rail and meets IEC and EN standards.
Solenso x SOLARC electrical protection means a safe consumer unit, a solar installation that keeps producing and a single contact in France.
